Scott Speedster Gravel 20

Scott Speedster Gravel 20
Color: Flat Green
Size: Select size
Please select options Unavailable
Sorry, this item is currently not available. Please check back.


The SCOTT Speedster Gravel 20 is your one-stop-shop for when the path gets less traveled. Comfortable geometry for all-day rides, room for big tires, and fully internal cable routing make this a great option for those looking to take it off road!

- Speedster Gravel Disc Alloy Frame
- Speedster Gravel Carbon Disc Fork
- Shimano GRX RX600/800 Disc, 22 Speed
- Syncros Race X25 Disc Wheels
- Schwalbe G-ONE Bite Tires

bike frame with labeled dimensions
Bike Sizes:
A. Reach 374.0mm 378.0mm 382.0mm 387.0mm 392.0mm 396.0mm 403.0mm
B. Stack 519.0mm 528.4mm 547.2mm 570.0mm 588.9mm 607.8mm 626.8mm
C. Standover 747.0mm 762.0mm 786.0mm 806.0mm 825.0mm 844.0mm 869.0mm
D. Effective Top Tube 512.3mm 523.0mm 536.5mm 556.5mm 571.2mm 581.2mm 594.2mm
E. Head Tube Angle 70.0 ° 70.0 ° 70.0 ° 71.0 ° 71.0 ° 71.0 ° 71.0 °
F. Head Tube Length 93.0mm 103.0mm 123.0mm 143.0mm 163.0mm 183.0mm 203.0mm
G. Seat Tube Angle 75.0 ° 74.5 ° 74.0 ° 73.0 ° 72.5 ° 72.5 ° 72.5 °
H. Seat Tube Length 470.0mm 490.0mm 520.0mm 540.0mm 560.0mm 580.0mm 610.0mm
I. Bottom Bracket Height 283.0mm 283.0mm 283.0mm 283.0mm 283.0mm 283.0mm 283.0mm
J. Bottom Bracket Drop -71.0mm -71.0mm -71.0mm -71.0mm -71.0mm -71.0mm -71.0mm
M. Wheelbase 1,019.5mm 1,026.9mm 1,037.7mm 1,044.9mm 1,056.4mm 1,067.0mm 1,071.3mm
O. Chainstay Length 435.0mm 435.0mm 435.0mm 439.0mm 439.0mm 439.0mm 439.0mm
Stem Length 73.0mm 83.0mm 93.0mm 103.0mm 103.0mm 113.0mm 113.0mm
BB To Top Tube Center 430.0mm 450.0mm 480.0mm 500.0mm 520.0mm 540.0mm 570.0mm


Frame Speedster Gravel Disc / D. Butted 6061 Alloy
SCOTT Gravel geometry / Replaceable Derailleur Hanger
Internal cable routing
Syncros fender kit ready
Fork Speedster Gravel HMF Flatmount Disc / 1 1/4"-1 1/2" Eccentric carbon steerer
Rims Syncros Race X25 Disc / 28 Front / 28 Rear
Hubs Front: Formula Team II CL Disc 28 H / Rear: Formula Team II CL Disc 28 H
Spokes Black 2mm
Tires Schwalbe G-ONE Bite Performance / 700x45c
Bottom Bracket Shimano BB-RS500 PB
Crankset Shimano GRX FC-RX600-11
Chainrings 46x30T
Shifters Shimano GRX ST-RX600 Disc / 22 Speed
Front Derailleur Shimano GRX FD-RX810-F
Rear Derailleur Shimano GRX RD-RX810
Cassette/Freewheel Shimano CS-HG700 / 11-34
Chain KMC X11
Brakes Shimano BR-RX400 hydraulic disc
Rotors Shimano SM-RT70 CL rotor 160/F and 160/R
Handlebars Syncros Creston 2.0 X / Alloy 31.8mm
Stem Syncros RR2.5 1 1/4" / four-bolt 31.8mm
Headset Acros AIF-1113
Seatpost Syncros RR2.5 27.2/300mm
Saddle Syncros Tofino Regular 2.5

* Subject to change without notice.

Part Numbers

Option UPC MPN
Flat Green / 47cm 192820605722 286456047
Flat Green / 49cm 192820605739 286456049
Flat Green / 52cm 192820605746 286456052
Flat Green / 54cm 192820605753 286456054
Flat Green / 56cm 192820605760 286456056
Flat Green / 58cm 192820605777 286456058
Flat Green / 61cm 192820605784 286456061
