Details
The SCOTT Speedster 20 is a light, agile, and cost-efficient alloy road bike. With fully integrated cables, not only will this bike ride well, but it will most definitely look the part!
KEY FEATURES
- Speedster Disc Alloy Frame
- Speedster Disc Carbon Fork
- Shimano Tiagra Disc, 20-speed
- Syncros Race 24 Disc Rims
- Schwalbe Lugano Tires
XXS/47 | XS/49 | S/52 | M/54 | L/56 | XL/58 | XXL/61 | |
---|---|---|---|---|---|---|---|
A. Reach | 376.0 mm | 383.0 mm | 387.0 mm | 391.0 mm | 385.0 mm | 399.0 mm | 406.0 mm |
B. Stack | 517.8 mm | 529.1 mm | 551.6 mm | 572.4 mm | 593.3 mm | 613.6 mm | 632.7 mm |
C. Standover | 735.0 mm | 754.0 mm | 780.0 mm | 800.0 mm | 820.0 mm | 840.0 mm | 864.0 mm |
D. Effective Top Tube | 515.0 mm | 525.0 mm | 540.0 mm | 554.0 mm | 569.0 mm | 583.0 mm | 596.0 mm |
E. Head Tube Angle | 70.5 ° | 71.0 ° | 72.0 ° | 72.5 ° | 73.0 ° | 73.3 ° | 73.3 ° |
F. Head Tube Length | 93.0 mm | 103.0 mm | 123.0 mm | 143.0 mm | 163.0 mm | 183.0 mm | 203.0 mm |
G. Seat Tube Angle | 75.0 ° | 75.0 ° | 74.5 ° | 74.0 ° | 73.5 ° | 73.1 ° | 73.0 ° |
H. Seat Tube Length | 470.0 mm | 490.0 mm | 520.0 mm | 540.0 mm | 560.0 mm | 580.0 mm | 610.0 mm |
I. Bottom Bracket Height | 275.3 mm | 275.3 mm | 275.3 mm | 275.3 mm | 275.3 mm | 275.3 mm | 275.3 mm |
J. Bottom Bracket Drop | -70.0 mm | -70.0 mm | -70.0 mm | -70.0 mm | -70.0 mm | -70.0 mm | -70.0 mm |
M. Wheelbase | 1,001.5 mm | 1,007.9 mm | 1,010.0 mm | 1,015.8 mm | 1,023.3 mm | 1,030.3 mm | 1,043.0 mm |
O. Chainstay Length | 425.0 mm | 425.0 mm | 425.0 mm | 425.0 mm | 427.0 mm | 427.0 mm | 427.0 mm |
BB To Top Tube Center | 430.0 mm | 450.0 mm | 480.0 mm | 500.0 mm | 520.0 mm | 540.0 mm | 570.0 mm |
Stem Length | 83.0 mm | 83.0 mm | 93.0 mm | 103.0 mm | 103.0 mm | 113.0 mm | 113.0 mm |
Specs
Frame |
Speedster Disc / 6061 D. Butted Alloy Endurance geometry / Internal cable routing Syncros fender kit ready |
---|---|
Fork | Speedster HMF Disc / 1 1/4"-1 1/2" Eccentric Carbon steerer |
Rims | Syncros Race 24 Disc / 28 Front / 28 Rear |
Hubs | Formula Team II CL Disc 28 H |
Spokes | Black 2mm |
Tires | Schwalbe Lugano / 700x32c |
Bottom Bracket | Shimano BB-RS500-PB |
Crankset | Shimano Tiagra FC-4700 / Hyperdrive |
Chainrings | 50x34T |
Shifters | Shimano Tiagra ST-4700 / Dual control / 20 Speed |
Front Derailleur | Shimano Tiagra FD-4700 |
Rear Derailleur | Shimano Tiagra RD-4700-GS |
Cassette/Freewheel | Shimano CS-HG500 / 10 Speed 11-32T |
Chain | KMC X10 |
Brakes | Shimano BR-RS305 black mechanical disc |
Rotors | Shimano SM-RT64 rotor 160/F and 160/R |
Handlebars | Syncros Creston 2.0 Compact / 31.8mm |
Stem | Syncros RR2.5 / 1 1/4" / four-bolt / 31.8mm |
Headset | Acros AIF-1113 |
Seatpost | Syncros RR2.5 27.2/350mm |
Saddle | Syncros Tofino Regular 2.5 |
* Subject to change without notice.
Part Numbers
Option | UPC | MPN |
---|---|---|
Green / 47cm | 192820603704 | 286430047 |
Green / 49cm | 192820603711 | 286430049 |
Green / 52cm | 192820603728 | 286430052 |
Green / 54cm | 192820603735 | 286430054 |
Green / 56cm | 192820603742 | 286430056 |
Green / 58cm | 192820603759 | 286430058 |
Green / 61cm | 192820603766 | 286430061 |
